Lightweight Kitchen Shutters

• Closes off the kitchen out of hours: Keeps the servery secure and tidy when it isn't in use.
• A neat finish for customers: The compact box and slim guides keep the counter looking tidy.
• Easy to lift: Light aluminium laths make hand operation simple on smaller hatches.
• Low upkeep: Aluminium resists corrosion and needs little maintenance.

Choose the slats, how you open the shutter and its colour.

Slats

• Solid: hides the kitchen completely when closed.
• Vented: lets air through. The vents only show when the shutter is partly open.

Manual

• Spring loaded: lift and lower by hand. The usual choice for serving hatches and counters.
• Swivel belt winder (up to 15kg), geared belt winder (15–25kg) or rod crank (up to 25kg) for larger openings.

Electric (shutters 750mm wide and over)

• Hold-to-run switch, rocker switch, security key switch, remote control or Somfy io smart control.
• Safety edge and obstacle detection. A manual override lets you open it in a power cut.

Colours

• Stocked: Brilliant White (RAL 9016).
• 20 non-standard colours: Cedar Woodgrain, Brown, Cream, Agate Grey, Anthracite Grey, Light Beige, Light Grey, Metallic Grey, Alu Metallic, Dark Brown, Moss Green, Fir Green, Creamy White, Steel Blue, Quartz Grey, Black Sablé, Grey Sablé, Golden Oak, Iron Glimmer and Beige.
• With Cedar Woodgrain, the bottom slat, box and guides come in brown.
• Swatches are a guide only. Non-standard colours may cost extra. See our colour chart.

• Security level: Low to medium
• Construction: All aluminium
• Lath: 42mm foam filled, twin walled extruded aluminium
• Curtain thickness: Approx. 9mm
• Curtain weight: 4.5kg/m²
• Maximum width: 3400mm (depending on height)
• Maximum height: 4000mm (depending on width)
• Box: Die cast aluminium end plates, two-piece roll formed aluminium casing
• Box size by clear opening height: Up to 1699mm: 165mm · 2099mm: 180mm · 2899mm: 205mm · 4000mm: 250mm
• Guide rails: H25 extruded aluminium with integral box section; 5mm high density pile brush seals
• Motor (electric): Single phase tubular motor inside the barrel
• Safety brake: Fitted on shutters over 25kg and on doorways
• Compliance: CE marked, UKCA

Supply only: made in 7–10 working days in Brilliant White, or up to 5 weeks in a non-standard colour. Delivery is usually a few days after manufacture.

Supply and installation: 3–4 weeks in total. We survey the site to confirm sizes, then manufacture and book your installation date.

Indicative prices (guide only):

Small (up to 1.5m x 1.5m):

• Supply only: £300–£600
• Supply & Install: £700–£1,200

Medium (up to 2.5m x 2.5m):

• Supply only: £500–£1,000
• Supply & Install: £1,000–£1,800

Large (up to 3m x 3m):

• Supply only: £800–£1,500
• Supply & Install: £1,500–£2,500

Your price depends on the hatch size, how many hatches you need, manual or electric opening, colour, vented slats and smart control. Installation also depends on access around fitted counters and equipment. Send us your sizes for an exact quote.
