Lightweight Bar Servery Shutter

Lightweight Aluminium Construction

Easier to operate, reduces strain on components, and extends product lifespan.

Cost Effective Security Solution

Ideal for low to medium security applications without the cost of heavy duty shutters.

Smooth & Quiet Operation

Suitable for customer facing environments such as bars, counters,kiosk and receptions.

Manual or Electric Operation Available

Flexibility to suit budget, usage frequency, and convenience requirements.

Compact Roll Design

Requires minimal headroom, making it perfect for restricted or retrofit installations.

Made to Measure Design

Manufactured to fit your exact opening for a clean, professional finish.

Wide Range of Colour Options

Available in a range of BS/RAL colours to match branding or surroundings.

Low Maintenance Requirements

Aluminium resists corrosion, reducing ongoing servicing and upkeep.

Suitable for Internal & External Use

Versatile solution for retail, commercial, and residential
applications.

Fast Lead Times Available

Efficient production and installation for projects with tighter deadlines

The RA2 Lightweight Aluminium Roller Shutter can be tailored to suit your opening, usage, and aesthetic requirements. From slat design to control method and finish, there are multiple configuration options available.

Slat Options

• Solid (Non-Vented) Slats
  Provides full privacy and security, ideal for back-of-house or internal areas.

• Vented Slats
  Allows airflow and partial visibility, commonly used for retail or counter shutters.

Operation & Control Options

Manual Operation (Cost-Effective & Simple):

• Belt Winder – Ideal for smaller shutters, easy and straightforward to use
• Rod Crank (Gear Operated) – Suitable for slightly larger openings with smoother control
• Spring & Lock (Push-Up Operation) – Simple manual lifting with bottom slat locking

Electric Operation (Convenience & Frequent Use):

• Hold-to-Run Switch – Press and hold for controlled opening and closing
• Remote Control (Fob Operation) – Open and close at the touch of a button
• Somfy IO Automation – Smart control with timers, group operation, and integration with home automation systems

Colour & Finish Options

• Standard Finish: White (RAL 9016)
• Popular Colours Available: Including Black, Anthracite Grey, and Brown

This flexibility allows the RA2 shutter to be configured for everything from simple internal security to more refined, customer facing
installations.

• Slat Type: Double skinned roll formed aluminium slats
• Slat Height: 42mm
• Curtain Thickness: Approx. 9mm
• Weight: Approx. 4kg/m²
• Maximum Width: Up to approx. 3800mm (height dependent)
• Maximum Height: Up to approx. 4000mm (width dependent)
• Guide Rails: 53mm W x 22mm Deep Extruded aluminium channels with brush seals.
• Bottom Rail: Reinforced aluminium bottom rail with rubber seal.
• Operation Types: Manual (belt, crank, spring) or electric motor operation
• Motor Options: Tubular motors (230V), including Somfy RTS iO
• Control Options: Key switch, rocker switch, remote control, smart automation (Somfy IO)
• Finish: Powder coated aluminium (standard RAL9016 or range of 10 other standard colours)
• Wind Rating: Suitable for low wind load / internal or sheltered external use
• Compliance: CE Marked / UKCA compliant (where applicable)
• Safety Options: Manual Override, safety brake, obstacle detection, safety edge (electric shutters)

We aim to keep lead times as efficient as possible for the RA2 Lightweight Aluminium Roller Shutter. Typical manufacturing time is 7–10 working days, with delivery usually arranged within a few days of completion. Please note, non-standard colours may increase lead times to approximately 5 weeks, depending on powder coating requirements. For supply-only orders, this still offers a relatively quick turnaround, making it a popular choice for time-sensitive projects.

For supply and installation projects, the full process typically takes 3–4 weeks. This includes an initial site survey to confirm sizes and requirements, followed by manufacture and scheduling of the installation. The RA2 shutter is straightforward to install, making it well-suited to supply only or DIY installation, provided accurate measurements are taken. Our team will guide you through the process to ensure everything is prepared correctly before
installation day.

The RA2 Lightweight Aluminium Roller Shutter is one of the most cost-effective shutter options, making it ideal for internal openings, kiosks, counters, and low risk external use.

Indicative Pricing (Guide Only)

Small (up to 1.5m x 1.5m)

• Supply Only - £300 – £600
• Supply& Install - £700 – £1,200

Medium (up to 2.5m x 2.5m)

• Supply Only - £500 – £1,000
• Supply & Installation - £1,000 – £1,800

Large (up to 3m x 3m)

• Supply Only - £800 – £1,500
• Supply & Install - £1,500 – £2,500

What Affects the Price?

• Operation Type – Manual options are more cost-effective; electric adds convenience and cost
• Slat Type – Vented slats may slightly increase pricing
• Colour Finish – Non-standard or custom colours increase cost and lead time
• Controls & Automation – Remote controls and smart (Somfy IO) systems add to the price
• Installation Complexity – Access, working height, and site conditions can affect install cost

Budget Guidance

• Manual shutters are ideal for lower budgets and occasional use
• Electric shutters are better suited for frequent use and ease of operation
• This product is best positioned as a light duty, cost effective solution, not for high-security or heavy industrial use

All prices are indicative and based on typical installations. For an
accurate quotation, we recommend providing sizes, operation preference, and installation details.
