Insurance Approved - Level 3 Retractable Security Grille

LPCB Certified Maximum Security Protection

CS13 retractable grille tested to LPS1175 Security Rating 3 (SR3) for advanced attack resistance

Designed for High-Risk Environments

Ideal for infrastructure, transport hubs, retail, and high-security commercial applications

Crowd Load Tested to 5kN/m

Certified to LU Standard 1-053 and BS EN 1991-1-1 for high footfall and impact resistance

Reinforced Steel Construction

Enhanced design with upgraded components for superior strength and durability

Internal Reveal Installation Only

Installed within masonry or structural steel openings to maintain certified performance

Smooth Top-Rolling Operation

Heavy-duty bearing system ensures reliable and controlled operation

High-Security Fixed Configuration

Engineered to maintain structural integrity and compliance with SR3 certification

Discreet Yet Robust Design

Provides strong protection while maintaining visibility and light flow

Custom Made to Measure

Manufactured to suit specific openings and complex project requirements

Suitable for Critical Infrastructure

Perfect for rail, transport, public sector, and high-security commercial environments

Low Maintenance, Long-Term Performance

Designed for durability in demanding, high-use environments

Compliant with Industry Standards

Meets strict security and structural testing requirements for certified applications

The CS13 Retractable Grille is engineered to meet strict LPS1175 SR3 certification and structural loading standards, meaning design flexibility is more controlled than lower-rated systems. However, it still offers key options to suit project-specific requirements, layouts, and aesthetics while maintaining full compliance.

Made-to-Measure Design

All CS13 grilles are manufactured to exact project dimensions:

• Designed for precise internal reveal installation only
• Suitable for windows, doors, and large structural openings
• Tailored to integrate with masonry or structural steel frameworks

Configuration Options

Designed for high-security fixed applications:

Single Sash

• Locks to one side and stacks to the opposite side
• Suitable for standard openings

Double Sash

• Locks centrally and retracts to both sides
• Ideal for wider openings and balanced access

Fixed Configuration

• Permanent installation where access is not required
• Provides maximum structural integrity

Lattice Design

• High-strength lattice configuration (security optimised)
• Engineered specifically to meet SR3 testing requirements
• Design cannot be altered beyond tested parameters

Installation Constraints (Certification Requirement)

• Internal installation only
• Must be fitted within the reveal of brickwork or structural steel
• Installation must comply with tested and approved fixing methods
• Ensures full compliance with LPS1175 SR3 and crowd load certification

Structural Integration

Designed to work with load-bearing substrates

Suitable for applications requiring resistance to:

• Forced entry attacks
• Crowd loading forces up to 5kN/m
• Ideal for integration into infrastructure and high-footfall environments

Stacking Options

• Single stack or double stack configurations
• Allows grille to retract efficiently within the opening
• Designed to maximise clear access while maintaining strength

Finish & Colour Options

• Available in standard powder-coated finishes
• Full RAL / BS colour range available for bespoke projects
• Designed to integrate with architectural finishes or branding

Security-Driven Design Limitations

To maintain certification:

• No hinge-around facility
• No alternative track configurations outside tested design
• All structural elements must remain within approved specification

Bespoke & Project-Specific Solutions

• Suitable for large-scale and complex installations
• Can be designed for transport hubs, rail environments, and public infrastructure
• Adaptable to meet LU Civil Standard 1-053 requirements

Application Flexibility

Ideal for:

• Transport infrastructure (rail, underground, stations)
• High-footfall commercial buildings
• Public sector and government facilities
• High-security retail and commercial environments

These design and customisation options ensure the CS13 delivers a fully compliant, high-security solution, balancing maximum protection, structural performance, and architectural integration in the most demanding environments.

Product Type:

• LPCB certified high-security retractable grille

Security Rating:

• Tested and certified to LPS1175 Issue 7/8 – Security Rating 3 (SR3)
• Certified by the Loss Prevention Certification Board (LPCB)
• Suitable for high-risk, security-critical environments

Additional Certification:

• Tested to LU Civil Engineering Standard 1-053
• Complies with BS EN 1991-1-1 (structural loading)
• Rated to withstand crowd loading forces up to 5kN/m

Construction:

• Heavy-duty reinforced steel construction
• Enhanced components designed for resistance to sustained and professional attack
• Fully engineered system for high-impact environments

Lattice Design:

• Security-optimised lattice configuration
• Designed specifically to meet SR3 certification requirements
• Non-adjustable beyond tested specification

Operation:

• Top-hung, top-rolling system
• Heavy-duty bearings for smooth and controlled operation
• Designed for frequent use in high-traffic environments

Locking System:

• High-security multi-point locking system
• Reinforced locking components for increased resistance
• Designed to maintain performance under attack conditions

Configurations:

• Single sash
• Double sash
• Fixed configuration (maximum security)

Stacking Options:

• Single stack or double stack
• Allows grille to retract efficiently within the opening

Installation Requirements:

• Internal installation only
• Must be installed within the reveal

Suitable substrates:

• Masonry (brick/concrete)
• Structural steel
• Installation must comply with LPCB-approved fixing methods

Design Constraints (Certification):

• No hinge-around facility
• No alternative track systems outside tested design
• Configuration must remain within certified parameters

Sizes:

• Made to measure to suit project requirements
• Suitable for large and complex openings (subject to design approval)

Finish:

• Powder coated as standard
• Full RAL / BS colour range available on request

Durability:

• Designed for high-use, high-impact environments
• Suitable for infrastructure and public access areas

Maintenance:

• Low maintenance system
• Periodic inspection of tracks, bearings, and locking mechanisms recommended

Application:

• Transport hubs, rail and underground stations
• Public buildings and high-footfall environments
• Commercial and high-security retail locations

Compliance:

• Must be installed in line with LPS1175 SR3 and structural testing requirements
• Installation directly affects certification validity

Warranty:

• Typically supplied with a 12-month manufacturer’s warranty (subject to specification)

The CS13 Retractable Grille is manufactured to order, with a typical lead time of 6–8 weeks from order confirmation and final specification. This reflects the advanced engineering, reinforced construction, and rigorous quality controls required to meet LPS1175 SR3 and structural loading certifications.

Lead times may vary depending on project size, configuration, and installation complexity, particularly for large openings or infrastructure projects. Due to the specialist nature of this product, accurate timescales will always be confirmed at quotation stage to align with your project programme.

The CS13 Retractable Grille is a high-security, LPCB-certified SR3 system, designed for environments requiring maximum resistance to sustained attack and crowd loading performance. As a result, it sits at the top end of the retractable grille range, with pricing reflecting its advanced engineering, certification, and installation requirements.

Indicative Pricing

Small Openings (Up to 1m²)

• Supply Only: £900 – £1,800
• Supply & Install: £1,400 – £2,800

Medium Openings (1m² – 3m²)

• Supply Only: £1,500 – £3,000
• Supply & Install: £2,200 – £4,500

Large Openings / Doors (3m²+)

• Supply Only: £3,000 – £6,000+
• Supply & Install: £4,500 – £8,500+

Large Infrastructure / High-Security Installations

• Supply Only: £5,000 – £12,000+
• Supply & Install: £7,000 – £15,000+

Factors Affecting Price

The final cost will depend on several critical factors:

• Security Rating: SR3 certified system with enhanced construction
• Opening Size: Larger spans significantly increase cost
• Configuration: Single sash, double sash, or fixed systems
• Structural Requirements: Installation into masonry or structural steel
• Crowd Load Compliance: Additional engineering for 5kN/m load resistance
• Finish: Standard powder coating vs bespoke RAL/BS colours
• Installation Complexity: High-security environments or restricted access

Installation Considerations

Due to its certified and structural nature, the CS13 requires:

• Installation in line with LPS1175 SR3 and structural testing standards
• Fixing into approved load-bearing substrates only
• Accurate alignment to maintain security and operational performance
• Potential coordination with structural engineers or main contractors

This results in higher installation costs compared to lower-rated systems.

Additional Costs to Consider

Structural preparation or reinforcement works

Bespoke colour finishes

• Access equipment (scaffolding, lifts)
• Installation in high-security or restricted environments
• Integration into infrastructure or transport projects

Budget Guidance

Typical budgets are:

• Commercial / retail applications: £2,000 – £5,000+ per opening installed
• High-security environments: £4,000 – £10,000+ per opening installed
• Infrastructure / transport projects: £7,000 – £15,000+ per installation

Get an Accurate Quote

Due to the specialist nature of the CS13, we recommend requesting a project-specific quotation. Our team can ensure the correct specification is selected to meet LPS1175 SR3, structural loading requirements, and site-specific security needs, while aligning with your project budget and programme.
