Steel Industrial Doors - LPS1175 Security Level 2

LPS1175 SR2 Certified Security

Tested to recognised security standards for protection against forced entry

Heavy Duty 18 Gauge Steel Slats

Solid single skin construction delivers high strength and durability

Internal Face Fix Installation

Fitted behind the opening so guides and box are not exposed to attack

100mm Windlock Guide System

Enhanced resistance to lateral force and curtain deflection

Reinforced T Section Bottom Rail

Improves structural integrity and security at the base of the shutter

Industrial Motor Operation (GFA Motors)

Inboard or outboard motors designed for heavy-duty, frequent use

Manual Bullet Locks (Required for Rating)

Additional physical locking for certified security performance

Designed for Medium to Large Openings

Suitable for openings up to 6200mm wide x 4550mm high

Made to Measure Design

Manufactured to suit your exact opening and installation requirements

Galvanised or Powder Coated Finish

Standard galvanised finish or colour matched in any RAL or BS colour

Ideal for High Risk Industrial Applications

Perfect for warehouses, distribution centres, and secure storage facilities

This high-security shutter is engineered to meet LPS1175 SR2 requirements, so design flexibility is more controlled than standard shutters. However, there are still key areas where the system can be tailored to suit your site and operation.

Curtain / Slat Specification

• Solid 18-Gauge Steel Slats (Standard)
  High-strength single skin galvanised steel
  Designed specifically to meet SR2 security rating

Installation Configuration

• Internal Face Fix Installation (Required)
  Installed behind the opening
  Prevents access to guides, curtain edges, and barrel
• Ensures compliance with security testing requirements

Guide & Bottom Rail System

• 100mm Windlock Guides (Standard)
  Provides enhanced resistance to forced entry and wind load
• Reinforced T-Section Bottom Rail
  Improves strength and prevents lifting or prying attacks

Motor & Operation Options

Industrial Electric Operation (Standard):

• GFA Inboard Motors – Compact within the barrel
• GFA Outboard Motors – Heavy duty for larger doors

Power Supply Options:

• 240V Single Phase
• 415V 3-Phase (recommended for larger shutters)

Control Options:

• Hold-to-run switch (standard)
• Key switch for controlled access
• Integration with access control systems

Security Features (Mandatory for SR2)

• Manual Bullet Locks
  Required as part of the certified security specification
• Dual layer security: electric operation + physical locking

Finish & Appearance

• Galvanised Finish (Standard)
  Durable and corrosion-resistant industrial finish
• Powder Coated Finish (Optional)
  Available in any RAL or BS colour
  Suitable for visible installations or branding requirements

Size & Configuration

• Maximum Size:
  Up to 6200mm (W) x 4550mm (H)
• Made to Measure Design
  Manufactured to suit exact structural opening and fixing method

Additional Considerations

• Designed primarily for security first applications
• Limited visual customisation to maintain certification integrity
• Ideal where insurance compliance and risk mitigation are key

This configuration ensures the shutter delivers certified protection, structural strength, and operational reliability, while still allowing controlled customisation to suit your site requirements.

Curtain & Slat Construction

• Slat Type: Single skin galvanised steel
• Slat Thickness: 18 gauge steel
• Slat Design: Solid slats only
• Curtain Weight: Approx. 14–18 kg/m² (depending on size)

Size Capabilities

• Maximum Width: Up to 6200mm
• Maximum Height: Up to 4550mm
• Maximum Area: Subject to motor and specification

Guide Rails & Bottom Rail

• Guide Rails: 100mm Windlock guides for enhanced security and stability
• Fixing Method: Face fixed internally behind opening
• Bottom Rail: Reinforced T-section steel bottom rail
• Locking: Manual bullet locks (required for SR2 rating)

Operation & Motor Options

• Operation Type: Electric (industrial motor only)
• Motor Type: GFA Industrial Motors - Inboard (chain drive), Outboard (direct drive)
• Power Supply Options: 230V single phase or 415V 3-phase (recommended for larger doors)

Control Options

• Hold to run switch (standard)
• Key switch for authorised access
• Integration with access control systems (optional)

Finish

• Standard Finish: Galvanised steel
• Optional Finish: Powder coated in any RAL or BS colour

Installation Requirements

• Installation Type: Internal face fix only
• Requirement: Guides and shutter box must not be exposed to attack side
• Critical for maintaining LPS1175 SR2 certification

Compliance & Security

• Security Rating: LPS1175 Security Rating 2 (SR2)
• Designed for high-security, insurance and compliance-driven applications

Safety Features

• Manual override (via motor system)
• Safety brake (where specified)
• Optional Light Curain or photocells (where required)

This specification ensures the shutter delivers certified high-security performance, structural strength, and reliable operation in demanding industrial environments.

We aim to keep lead times as efficient as possible for the Steel Industrial Doors - LPS1175 Security Level 2 , with typical manufacturing taking approximately 4 weeks. Delivery is usually arranged shortly after completion. Please note that larger doors and powder coated finishes may extend lead times by up to an additional 2 weeks, depending on specification and requirements.

For supply and installation projects, the full process typically takes 4–7 weeks. This includes an initial site survey to confirm sizes, structural requirements, and motor specification, followed by manufacture and scheduling of installation.

Due to the size and weight of industrial shutters, professional installation is strongly recommended, particularly where GFA industrial motors (240V or 415V) are specified. Our team will guide you through the process to ensure accurate measurements, correct motor selection, and a smooth, reliable installation.

The Steel Industrial Roller Shutter (SR2) is a high security, certified solution, positioned at the upper end of the market due to its LPS1175 testing, reinforced construction, and specialist installation requirements.

Indicative Pricing (Guide Only)

Small (up to 3m x 3m)

• Supply Only – £3000 – £5,000
• Supply & Install – £5,000 – £8,500

Medium (up to 5m x 4m)

• Supply Only – £5,500 – £10,000
• Supply & Installation – £9,000 – £16,000

What Affects the Price?

• LPS1175 SR2 Certification – Tested, reinforced components increase cost
• Internal Face Fix Installation – More complex installation to meet security requirements
• Motor Specification – 415V industrial motors increase cost for larger doors
• Windlock Guide System – Heavy-duty guides add to overall cost
• Manual Bullet Locks – Required for certification and included in specification
• Finish – Powder coating (RAL/BS) increases cost and lead time
• Installation Complexity – Structural works and access impact pricing

Budget Guidance

• A premium upgrade from standard industrial shutters, offering certified high security
• Ideal for warehouses, logistics hubs, and high risk commercial environments
• Best suited where insurance compliance, risk reduction, and security are critical

All prices are indicative and based on typical installations. For an accurate quotation, we recommend providing sizes, installation details, and security requirements.
