Lightweight Sliding Shutter

Effortless Manual Operation

Smooth, top-hung sliding system allows easy opening and closing with no motors or power required, ideal for daily use

Space-Saving Design

Panels slide neatly to the side with no bulky headbox or floor tracks, maximising usable space and maintaining a clean finish

Lightweight Yet Durable Construction

Manufactured from high-quality aluminium, offering a balance of strength, reliability, and ease of operation

Ideal for Internal Commercial Applications

Perfect for kiosks, retail counters, airport units, bar serveries, and reception desks

Custom-Made to Suit Any Opening

Fully bespoke design tailored to your exact width, height, and layout requirements

Flexible Configuration Options

Available as:

• Single sliding units
• Bi-parting shutters
• Curved or angled layouts for bespoke spaces

Multiple Panel & Infill Choices

Choose from solid, perforated, or vision panels to balance security, visibility, and airflow

Secure Locking Options

Includes flush locks, espagnolette bolts, or keyed systems, with optional intermediate locks for wider spans

Clean, Modern Aesthetic

Available in six standard anodised aluminium finishes, suitable for contemporary commercial interiors

Top-Hung System with No Trip Hazards

Eliminates floor tracks, ensuring a safe, unobstructed floor area

Low Maintenance & Reliable

Simple design with minimal moving parts reduces maintenance and ensures long-term performance

Ideal for Low to Medium Security Applications

Provides effective internal security for protected environments and commercial spaces

The Lightweight Sliding Shutter is designed to provide a high level of flexibility for internal commercial environments, combining bespoke sizing, multiple configurations, and a range of panel options. While the system is intentionally simple and manual, it offers extensive customisation to suit different layouts and operational needs.

Configuration Options

Single Sliding Shutter:

• Panels slide to one side
• Ideal for smaller openings or restricted spaces

Bi-Parting Shutter:

• Panels slide from the centre to both sides
• Suitable for wider openings and improved access

Curved or Angled Layouts:

Track can be manufactured to suit:

• Curved counters
• Kiosks
• Non-linear or bespoke openings

Panel & Infill Options

Standard Open Grille Construction:

• Curtain formed using 12mm aluminium tubes centred on a solid core
• Tubes linked horizontally with an aluminium connecting profile
• Provides visibility and airflow while maintaining a lightweight structure

Each panel section includes:

• 102mm high aluminium top and bottom rails
• Manufactured from 2mm thick aluminium extrusion
• Connected using extruded hinge cleats with a 15° offset to enable smooth folding

Important:

The standard design is an open grille, meaning it can be accessible by hand or arm and is therefore suited to internal, low to medium security applications only.

Alternative Panel Options:

Solid Panels:

• Provides full visual screening and privacy

Perforated Panels:

• Allows partial airflow and limited visibility

Polycarbonate Vision Panels:

• Clear panels for visibility, display, and light transmission

Construction Note:

• All panels are single skin only
• Double skin options are not available

Size & Bespoke Design

• Fully made-to-measure

Manufactured to suit:

• Opening width and height
• Complex shapes or layouts

Suitable for:

• Straight openings
• Curved installations
• Multi-section applications

Track & Operation Design

Top-Hung Sliding System:

• Panels run on overhead rollers within a head track

Bottom Guide:

• Maintains alignment without intrusive floor tracks

No Headbox Required:

• Clean, space-saving alternative to roller shutters

Locking Options

• Flush Locks
• Espagnolette Locking Systems
• Keyed Cylinder Locks
• Intermediate Post Locks (for wider openings)

Designed to provide secure closure while maintaining a minimal aesthetic

Finish Options

Available in anodised aluminium finishes only:

• Natural Anodised
• White
• Black
• Light Bronze
• Medium Bronze

Important:

This product is not available with powder coating, ensuring a consistent and durable anodised finish.

Safety & Functional Design

• Top-hung system eliminates floor trip hazards
• Finger-safe track design with rounded profiles
• Optional emergency access / quick-release features (subject to specification)
• Lightweight construction ensures safe and easy manual operation

Design Summary

The Lightweight Sliding Shutter is built around:

• Space-saving, top-hung design
• Manual simplicity with smooth operation
• Open grille construction for visibility and airflow
• Flexible panel options for privacy or display
• Consistent anodised finishes for a clean, modern look

These design and customisation options make the system ideal for retail kiosks, counters, and internal commercial environments, where aesthetics, usability, and efficient use of space are key considerations.

Product Type:

• Internal manual sliding security shutter (top-hung system)

Application:

• Retail kiosks and shopping centres
• Airport counters and exhibition units
• Bar serveries and cafés
• Reception desks and internal counters
• Commercial display and concession units

Construction

Material:

• Aluminium Alloy 6063-T5
• Lightweight yet durable construction for internal, low to medium security use

Curtain / Panel Design

Standard Open Grille Construction:

• 12mm aluminium tubes centred on a solid core
• Tubes connected via horizontal aluminium linking profiles

Top & Bottom Rails:

• 102mm high aluminium panels
• Manufactured from 2mm thick aluminium extrusion

Hinge System:

• Connected using extruded hinge cleats
• 15° offset to enable smooth folding and stacking

Important:

• Open grille design allows visibility and airflow but can be accessible by hand/arm

Alternative Panel Options

• Solid Panels – full privacy and visual screening
• Perforated Panels – partial airflow and limited visibility
• Polycarbonate Vision Panels – clear infill for display and light

Construction:

• Single skin only
• Double skin panels not available

Operation

• Manual operation only
• Sliding action via top-mounted rollers
• No motors, electrics, or automation required
• Track System

Top-Hung Track:

• Aluminium head track with integrated roller system

Bottom Guide:

• Discreet guide to maintain alignment
• No intrusive floor track required
• Ensures smooth, quiet operation

Configuration Options

• Single sliding (stacking to one side)
• Bi-parting (centre opening)
• Curved or angled layouts available

Sizes

• Fully made-to-measure
• Manufactured to suit specific opening width and height
• Suitable for straight or complex openings

Locking System

• Concealed cylinder locks on end posts

Optional:

• Flush locks
• Espagnolette locking
• Intermediate locking posts for wider spans

Finishes

Available in anodised aluminium finishes only:

• Natural Anodised
• White
• Black
• Light Bronze
• Medium Bronze
• Powder coating not available

Safety Features

• Top-hung design eliminates floor trip hazards
• Finger-safe track profiles reduce pinch points
• Smooth manual operation reduces operational risk
• Optional emergency access or quick-release features

Installation

Mounting Options:

• Soffit fixed
• Face fixed to wall or ceiling structure

Suitable for:

• Steel frameworks
• Timber structures
• Solid substrates
• Professional installation recommended for alignment and performance

Maintenance

• Low maintenance system

Periodic checks of:

• Rollers and track
• Locking mechanisms
• Fixings and alignment

Warranty

• Typically supplied with a 12-month manufacturer’s warranty (subject to confirmation)

Performance Summary

• Lightweight and easy to operate
• Space-saving design with no headbox or floor track
• Suitable for internal environments
• Provides visual security rather than high-security resistance

This technical specification defines the Lightweight Sliding Shutter as a practical, low-maintenance, and highly adaptable internal security solution, ideal for commercial environments where space, appearance, and ease of use are key priorities.

Lead Times

The Lightweight Sliding Shutter is a made-to-measure product, manufactured to suit your exact opening size and configuration.

Typical manufacturing lead time:

Approximately 4 weeks from order confirmation and approved drawings

Lead times may vary depending on:

• Size and complexity of the opening (e.g. curved or angled designs)
• Panel type selected (open grille, solid, perforated, or polycarbonate)
• Configuration (single slide or bi-parting systems)
• Order quantity

All lead times will be confirmed at quotation stage to align with your project programme.

Installation

The Lightweight Sliding Shutter is designed for straightforward installation, however accurate alignment is critical for smooth long-term operation.

Installation Options

Soffit Fix:

Mounted directly to the underside of the structure

Face Fix:

Mounted to the wall or structural framework above the opening

Suitable for installation onto:

• Steel frameworks
• Timber structures
• Masonry or solid substrates

Installation Requirements

• Level and structurally sound fixing surface
• Adequate support for top track system
• Sufficient side room for panel stacking
• Clearance for smooth sliding operation

Installation Process

• Fixing of top track system
• Installation of bottom guide (if required)
• Hanging and aligning sliding panels
• Adjustment of rollers and tracking
• Installation and testing of locking system

Professional Installation

Professional installation is recommended to ensure:

• Accurate alignment of track and panels
• Smooth and reliable operation
• Correct integration with locking systems

Post-Installation

• Shutter is tested for smooth operation
• Locks and alignment checked
• Basic user guidance provided

This combination of fast manufacture and straightforward installation makes the Lightweight Sliding Shutter an ideal solution for projects requiring a quick turnaround, minimal disruption, and a clean internal finish.

The Lightweight Sliding Shutter is a bespoke, made-to-measure system, with pricing influenced by size, configuration, and panel type. It offers a cost-effective internal security solution compared to automated shutters, particularly for kiosks, counters, and commercial interiors.

Indicative Pricing

Small Openings (Up to 1.5m W x 1.5m H)

• From £2,000 – £3,000 + VAT

Standard Opening (Approx. 2m W x 2m H)

• From £3,500 + VAT

Medium Openings (2m – 4m wide)

• From £3,500 – £6,500 + VAT

Larger Openings (4m+ wide / bi-parting systems)

• From £6,500 – £10,000+ + VAT

Configuration Impact on Price

Single Sliding Units:

• Most cost-effective option

Bi-Parting Systems:

• Add approx. +10–20% due to additional panels and track

Curved or Bespoke Layouts:

• Add approx. +15–30% depending on complexity
• Panel Options Impact on Price

Standard Open Grille:

• Base specification

Solid Panels:

• Slight increase depending on material

Perforated Panels:

• Typically similar to standard or slight uplift

Polycarbonate Vision Panels:

• Add approx. +10–25% depending on extent

Factors Affecting Price

• Opening width and height
• Panel type and design
• Configuration (single, bi-parting, curved)
• Number of panels and stacking requirements
• Locking options and additional features
• Site conditions and installation requirements

Installation Costs

Professional Installation (Recommended):Typically £300 – £1,000+ depending on size and complexity

Budget Guidance

• Small kiosks / counters: £2,000 – £4,000 + VAT
• Standard retail units: £3,500 – £6,500 + VAT
• Large or bespoke installations: £6,500 – £10,000+ + VAT

Why It’s Cost Effective

• No motors or electrics required
• Minimal maintenance costs
• Space-saving design (no headbox or floor tracks)
• Fully bespoke to suit your layout

Get an Accurate Quote

Due to the bespoke nature of the system, we recommend requesting a tailored quotation to ensure the design, configuration, and pricing meet your exact project requirements.
