Why use the Polycarbonate Internal Sliding Security Shutter?
With no floor tracks required, the Polycarbonate Internal Sliding Security Shutters are suspended from a continuous overhead track and are manually operated in a slide-aside action. They do not require removable mullions or fixed posts as all components, including locking mechanisms, are integral. The Sliding Shutters are ideal when there is not enough headroom for a roller shutter. The Polycarbonate Internal Sliding Security Shutter is that they can cover widths up to 80m wide and they can go around 45 and 90 degrees curves.
The Polycarbonate Internal Sliding Security Shutter provides 90% Vision and Maximum security. The Sliding Shutter is available in 3 other designs; Solid, Perforated and Brick bond.
ThePolycarbonate Internal Sliding Security Shutter comes in Anodised Silver, Black, White, Medium Bronze and Light Bronze as standard. The shutters can be Powder Coated any BS or RAL colour to match your colour scheme.
Commercial, Retail, Bar and Serveries
Polycarbonate - 90% Vision
Max Height - Manual
Curtain - Standard Finish
Anodised Silver, Black, White, Medium Bronze, Light Bronze
15 working days
The top and bottom of each panel section is fitted with a 102mm high aluminium panel. This panel consists of an aluminium extrusion 2mm thick. It is connected into extruded hinge cleats with a 15° off set to facilitate folding. The curtain is constructed of 152mm wide modules linked together by a continuous aluminium hinge. These hinges hold different curtain designs created by using different infils – in this case 2mm thick Makrolon Polycarbonate.
TOP TRACK DETAILS Manufactured from a strong tempered aluminium alloy class 6351 –T6 Extrusion, 34mm wide x 42mm total height.
Lock members are integral 50mm x 32mm standard extruded hollow posts. They are at both ends of each shutter or grille, at intervals of 2500mm maximum and at every curve (on countertops, specify at 1500mm maximum spacing).. Choose from seven different types of lock member. Lead posts incorporate Adams Rite Mortice Locks operated by 5-pin cylinders on each side. Immediate posts incorporate drop bolts locating into flush floor sockets. Drop bolts can be deadlocked with 5-pin cylinders.
The top of alternate panels is connected into the overhead track by a suspension rod and pairs of trolley wheels. Simply pull or push the Sliding Shutter to open or close. Any length of Sliding Shutter can be manually operated by a single person.
The Standard colour is Anodised Silver. Other colours available on request.
