Fully Glazed Door Systems

Slimline Fully Glazed Thermally Insulated Doors

From only £2,995

Based on 800mm x 1900mm

instant quote icon

Key Product Features

Applications

Domestic, Commercial, Retail, Leisure

Door Type

Available as Single, Leaf & Half or Double Dorsets

Fire Rated

Yes

Material

Galvanised Steel

Locking Hardware

Personnel, Fire Exit, Electromechanical Furniture

Door Leaf Core

No Core

Glazing Options

Options Available

Standard Finish

Grey Primer or Powder Coated Stock RAL / BS Colour

Lead Times

30-40 working days

Why use the Janisol 2 - Thermally Insulated Fully Glazed Steel Doors?

Thermally insulated steel profile system for multi-functional door constructions. The steel profile system enables a wide variety of constructions for aesthetically and structurally demanding multi-functional single and double-leaf steel doors in outdoor areas – perfect for use in heavily frequented public buildings. The stainless steel profile system option is conceived for elegant thermally insulated door constructions with the highest requirements in functionality, security and design – ideally suited for use in coastal and industrial zones and in care-related and hygiene-critical areas. The compatibility of Janisol steel door systems guarantees visually uniform solutions even when there are a number of different security requirements: non-insulated Jansen Economy doors for indoor use and smoke protection as well as Janisol 2, Janisol C4 fire protection systems can be combined.

Materials/surface finishes

Uncoated or strip-galvanised steel, suitable for powder coating or stove-enamelling

Stainless steel 1.4401 (AISI 316) or 1.4301 (AISI 304) (smoothed on request)

Element types

Single and double steel doors, with or without side panels and transom windows, inward and outward-opening

Single and double stainless steel doors, with or without side panels and transom windows, inward and outward-opening

Sheet metal clad steel doors with or without vision panels

Anti-finger-trap door

Equipment

Steel and stainless steel hinges for welding or screw-fitting

Integrated door closers

Designer glazing beads

Emergency locks and panic push-bars

Special technical features

Installation depth 60 mm

Special geometries (semi-circular tops)

Structural glazing leaf as special solution

Pivot door made of steel or

stainless steel as special solution

Janisol anti-finger-trap door

Test certificates

CE marking in accordance with product standard EN 14351-1

Tightness against heavy rain up to class 4A

Air permeability up to class 4

Resistance to wind load up to class C4/B4

Airborne sound insulation up to Rw 45 dB

Coefficient of thermal transmittance UD > 1.5 W/m2K

Shear bonding in accordance with EN 14024

Durability in accordance with EN 12400 class 8

Burglar resistance in accordance

with EN 1627 up to RC (WK) 3

Bullet resistance FB 4-6

TRAV

Emergency exit door in accordance with EN 1125 / EN 179

Downloads

Need more information?

Speak to one of our specialist advisors for more information about this product.

Use our intuitive product selector to help you find the right product.

Product Selector
