Fire and Smoke Curtains

Security Features

•    Provides a critical passive fire protection barrier, helping compartmentalise buildings during fire emergencies.
• No manual or electric locking mechanisms required—activates automatically during a fire event.
• Designed to meet EN 13501-2 classifications for fire resistance, ensuring compliance with safety standards.


Safety Features

•    Tested and rated to E120 and EW30/EW60 standards, offering up to 120 minutes fire integrity and 30–60 minutes smoke containment and heat radiation control.
• Equipped with gravity fail-safe operation, ensuring the curtain descends safely under its own weight if power fails.
• Includes battery backup system for continued operation during power outages.
• CE-marked to EN 16034 and EN 13241 for compliance with both fire curtain and powered pedestrian door regulations.


Fire Safety

•    Certified to provide E (Integrity) and EW (Integrity + Radiation Control) ratings under EN 13501-2, reducing fire spread and radiant heat.
• Constructed with a glass fibre fabric reinforced with stainless steel wire and a specialist coating that resists fire and limits heat transmission.
• Helps maintain escape routes and reduce flashover risk by containing both flame and radiant heat for up to 2 hours.
• Ideal for buildings requiring multi-zone fire compartmentation without the need for rigid barriers.


Design & Customisation

•    Compact headbox design allows for discreet integration into ceilings or soffits, maintaining architectural aesthetics.
• Available in a range of headbox sizes to suit installation space and drop height requirements.
• Finish typically in RAL 9005 black or RAL 9016 white, with custom colours on request.


Operation & Controls

•    Electrically operated via 24V DC motor system controlled by digital control panel (FC-INTUM).
• Integrated with building management systems or fire alarm interfaces to deploy automatically upon fire detection.
• Includes manual reset and test switch for maintenance and inspection purposes.
• Optional audio-visual warning systems (e.g., beacons and sounders) for enhanced safety during deployment.


Installation & Warranty

•    Supplied made-to-measure, ensuring compatibility with each specific application and fire strategy.
• Can be installed as a face fix or reveal fix, offering flexibility to installers.
• Certified for installation only into masonry walls or 80mm x 80mm x 5mm mild steel box section, ensuring full compliance with fire safety standards and test conditions.
• Comes with warranty (12 months), subject to maintenance compliance and registration.


Lead Time & Common Applications

•    Standard lead time typically 3–5 weeks depending on size and configuration.
• Ideal for retail environments, hospitals, airports, offices, hotels, and public buildings where smoke and fire containment is essential but space is limited.
• Suitable for open-plan areas, atriums, and lobbies where traditional fire doors are impractical.
